Product details
Profile
Ideal for freestyle: great pop and easy landings
Shape
Wide nose and narrow tail for amazing float in powder
Article number
Riding Style
- Touring
- Freeride
Riding Level
- Advanced
Stiffness
- 6
Flex
- Medium
Country of production
- Austria
Gender
- Men
Base
- Sintered
Compatibility
- Standard Inserts
| Size | 155 | 158 | 161 | 164 |
|---|---|---|---|---|
| Length (cm) (cm) | 155 | 158 | 161 | 164 |
| Nose Width (cm) | 30.1 | 30.5 | 31 | 31.5 |
| Rider Weight (kg) | 59 - 86 | 68 - 90 | 72 - 95 | 77 - 105 |
| Running Length (cm) | 118.2 | 119.5 | 122.2 | 123.8 |
| Setback (mm) | 20.32 | 20.32 | 20.32 | 20.32 |
| Sidecut Radius (m) | 8.0/6.8/8.0 | 8.1/7.0/8.1 | 8.3/7.2/8.3 | 8.5/7.4/8.5 |
| Snowboard width | Regular | Regular | Regular | Regular |
| Tail width (cm) | 29 | 29.3 | 29.7 | 30.1 |
| Waist Width (cm) | 25.2 | 25.6 | 26 | 26.4 |
Product description
Grip on the way up, float on the way down
The Navigator is one of the big powder favourites in the CAPiTA line-up, and the Navigator Split brings it back as a factory-built splitboard. It opens up new terrain in the sidecountry, or lets you skin up your favourite resort line where uphill travel is allowed. Camber underfoot keeps your climbs light and controlled. On the way down, the narrower tail sinks into the powder while the wider nose floats on top, and the parabolic sidecut carries you through deep snow in smooth, flowing turns.
Light on the climb, lively on the descent
The split-specific core pairs weight-graded poplar with paulownia, so the board stays light for long skin tracks without losing its signature pop. Technora™ Flax Boosters work as shock absorbers while adding power for turns and ollies. A raised camber platform between the inserts holds your edge at speed in variable conditions, elevated contact points help you land and float, and Flat Kick arcs in the tip and tail make edge-to-edge transitions quicker. The Navigator Split is built at CAPiTA's MotherShip in Austria using 100% clean energy. It's a strong setup for splitboarders chasing powder stashes away from the crowds.
- Shape: Directional with 0.8-inch setback
- Profile: Resort V2 Directional + Flat Kick Tech (hybrid camber)
- Sidecut: Parabolic Radical Taper
- Flex: Directional 6 (1 = soft, 10 = stiff)
- Core: 3D Ascend 2 Split Core™ with ABS centreline
- Additives: 2 × 30mm Technora™ Flax Boosters
- Glass + resin: Holysheet™ Tri/Tri fibreglass, Magic Bean™ resin with 60% bio-content
- Base: HyperDrive™ sintered base
- In the box: Union Expedition Skins by Montana™, Union Pro Clips and Hooks
